AS22284 U.S. Department of the Interior

AS22284 U.S. Department of the Interior announces 212 IPv4 prefixes and 1 IPv6 prefix. The map below is for 140.216.0.0/14, the largest of them that RIPE RIS can see: 330 collector peers reach it over 253 AS paths, through one upstream, AS3356 Level 3 Parent, LLC.

Routes checked 19:08:29 UTC

No change in the origin, the upstreams or the number of peers since 19:08 UTC, when this site first looked at 140.216.0.0/14.

AS-path graph toward 140.216.0.0/14
BGP map of 140.216.0.0/1411 networks on the paths RIPE RIS collector peers use to reach 140.216.0.0/14. Best path, chosen by the most peers: AS24482 → AS2914 → AS3356 → AS22284.AS8218 → AS6461 · 7 routesAS6461 → AS3356 · 12 routesAS49544 → AS3356 · 5 routesAS199524 → AS1299 · 5 routesAS1299 → AS3356 · 9 routesAS9002 → AS3356 · 4 routesAS13030 → AS1299 · 4 routesAS24482 → AS2914 · 11 routes · best pathAS2914 → AS3356 · 14 routes · best pathAS3356 → AS22284 · 57 routes · best pathAS22284 → 140.216.0.0/14 · 57 routes · best path7AS8218 → AS6461 · 7 routes12AS6461 → AS3356 · 12 routes5AS49544 → AS3356 · 5 routes5AS199524 → AS1299 · 5 routes9AS1299 → AS3356 · 9 routes4AS9002 → AS3356 · 4 routes4AS13030 → AS1299 · 4 routes11AS24482 → AS2914 · 11 routes · best path14AS2914 → AS3356 · 14 routes · best path57AS3356 → AS22284 · 57 routes · best path57AS22284 → 140.216.0.0/14 · 57 routes · best pathT1AS3356Level 3 Parent, LLCAS3356 Level 3 Parent, LLC · Tier 1 · 57 routes · on the best pathAS22284U.S. Departmentof the InteriorAS22284 U.S. Department of the Interior · origin · 57 routes · on the best pathT1AS2914NTT America, Inc.AS2914 NTT America, Inc. · Tier 1 · 14 routes · on the best pathT1AS6461Zayo BandwidthAS6461 Zayo Bandwidth · Tier 1 · 12 routesAS24482SG.GSAS24482 SG.GS · edge network · 11 routes · on the best pathT1AS1299TWELVE99 ArelionSweden ABAS1299 TWELVE99 Arelion Sweden AB · Tier 1 · 9 routesAS8218NEO-ASN ZayoInfrastructure France SAAS8218 NEO-ASN Zayo Infrastructure France SA · edge network · 7 routesAS49544i3Dnet i3D.net B.VAS49544 i3Dnet i3D.net B.V · edge network · 5 routesAS199524GCORE G-Core Labs S.A.AS199524 GCORE G-Core Labs S.A. · edge network · 5 routesT2AS9002RETN-AS RETN LimitedAS9002 RETN-AS RETN Limited · Tier 2 · 4 routesT2AS13030INIT7 Init7(Switzerland) Ltd.AS13030 INIT7 Init7 (Switzerland) Ltd. · Tier 2 · 4 routes140.216.0.0/14140.216.0.0/14

origin Tier 1Tier 2edge network prefix best path: chosen by 11 of 330 peers (3%) number on a line = peers using that link RIS data up to 19:07 UTC what the colours mean 12 of 253 paths drawn 4 quieter networks left out

Download PNG View JSON Raw upstream Full map of 140.216.0.0/14 →

Upstreams of 140.216.0.0/14

Networks directly in front of the origin, counted over the paths the collector peers use.

NetworkPeersShare
AS3356 Level 3 Parent, LLC330100%

IPv4 prefixes (212)

The 200 largest are listed. All 212 on RIPEstat.

IPv6 prefixes (1)

Prefixes announced in the last two weeks, as seen by RIPE RIS.
