BGP map for 159.189.240.0/20

159.189.240.0/20 is announced by AS22284 U.S. Department of the Interior and seen by 329 peers of 23 RIPE RIS collectors, over 249 different AS paths. All of those routes reach it through one upstream, AS3356 Level 3 Parent, LLC. The most common path, used by 11 peers, is AS24482 AS2914 AS3356 AS22284.

Routes checked 21:24:42 UTC

No change in the origin, the upstreams or the number of peers since 21:24 UTC, when this site first looked at 159.189.240.0/20.

AS-path graph toward 159.189.240.0/20

origin Tier 1Tier 2edge network prefix best path: chosen by 11 of 329 peers (3%) number on a line = peers using that link RIS data up to 21:24 UTC what the colours mean 12 of 249 paths drawn 4 quieter networks left out

Download PNG View JSON Raw upstream

329collector peers

23RIS collectors

249distinct AS paths

3.9average AS hops, 3 to 6

Upstreams

Networks directly in front of the origin.

Network	Peers	Share
AS3356 Level 3 Parent, LLC	329	100%

Transit networks

Networks between the collector peer and the origin.

Network	Peers	Share
AS3356 Level 3 Parent, LLC	329	100%
AS1299 TWELVE99 Arelion Sweden AB	49	15%
AS2914 NTT America, Inc.	36	11%
AS174 Cogent Communications, LLC	17	5%
AS6461 Zayo Bandwidth	11	3%
AS3257 GTT-BACKBONE GTT Communications Inc.	11	3%
AS6939 Hurricane Electric LLC	8	2%
AS6762 SEABONE-NET TELECOM ITALIA SPARKLE S.p.A.	7	2%
AS3320 DTAG Deutsche Telekom AG	7	2%
AS1764 NEXTLAYER-AS Next Layer Telekommunikationsdienstleistungs- und Beratungs GmbH	7	2%

AS paths

Every distinct path the collector peers use, most common first. An ASN repeated to lengthen a path (a prepend) is shown once.

#	Path, collector peer to origin	Peers	Share	Collectors
1	AS24482 AS2914 AS3356 AS22284	11	3%	11
2	AS8218 AS6461 AS3356 AS22284	7	2%	6
3	AS199524 AS1299 AS3356 AS22284	6	2%	6
4	AS6461 AS3356 AS22284	5	2%	5
5	AS49544 AS3356 AS22284	5	2%	4
6	AS9002 AS3356 AS22284	4	1%	4
7	AS14840 AS3356 AS22284	4	1%	2
8	AS13030 AS1299 AS3356 AS22284	4	1%	4
9	AS2914 AS3356 AS22284	3	<1%	3
10	AS3491 AS3356 AS22284	3	<1%	3
11	AS48185 AS3356 AS22284	3	<1%	3
12	AS35280 AS3356 AS22284	3	<1%	3
13	AS25091 AS3356 AS22284	3	<1%	3
14	AS12779 AS3257 AS3356 AS22284	3	<1%	3
15	AS34927 AS1299 AS3356 AS22284	3	<1%	3
16	AS51185 AS6762 AS3356 AS22284	3	<1%	3
17	AS3257 AS3356 AS22284	2	<1%	2
18	AS6830 AS3356 AS22284	2	<1%	2
19	AS3320 AS3356 AS22284	2	<1%	2
20	AS62167 AS3356 AS22284	2	<1%	2
21	AS1299 AS3356 AS22284	2	<1%	2
22	AS50628 AS3356 AS22284	2	<1%	2
23	AS31027 AS3356 AS22284	2	<1%	1
24	AS8529 AS3356 AS22284	2	<1%	2
25	AS6762 AS3356 AS22284	2	<1%	2
26	AS59890 AS3356 AS22284	2	<1%	2
27	AS271253 AS3356 AS22284	2	<1%	1
28	AS2497 AS3356 AS22284	2	<1%	2
29	AS25160 AS2914 AS3356 AS22284	2	<1%	2
30	AS58057 AS1836 AS3356 AS22284	2	<1%	2
31	AS35710 AS3320 AS3356 AS22284	2	<1%	2
32	AS14907 AS2914 AS3356 AS22284	2	<1%	2
33	AS34019 AS35625 AS3356 AS22284	2	<1%	2
34	AS15547 AS174 AS3356 AS22284	2	<1%	2
35	AS51184 AS1764 AS3356 AS22284	2	<1%	2
36	AS48362 AS1764 AS3356 AS22284	2	<1%	2
37	AS47692 AS33891 AS3356 AS22284	2	<1%	2
38	AS47147 AS1299 AS3356 AS22284	2	<1%	2
39	AS19151 AS2914 AS3356 AS22284	2	<1%	2
40	AS58057 AS34549 AS2914 AS3356 AS22284	2	<1%	2
41	AS20612 AS9044 AS1299 AS3356 AS22284	2	<1%	1
42	AS142289 AS9583 AS4755 AS6453 AS3356 AS22284	2	<1%	1
43	AS7018 AS3356 AS22284	1	<1%	1
44	AS37721 AS3356 AS22284	1	<1%	1
45	AS50300 AS3356 AS22284	1	<1%	1
46	AS17639 AS3356 AS22284	1	<1%	1
47	AS3549 AS3356 AS22284	1	<1%	1
48	AS14907 AS3356 AS22284	1	<1%	1
49	AS6057 AS3356 AS22284	1	<1%	1
50	AS198150 AS3356 AS22284	1	<1%	1

50 of 249 paths shown. All of them are in the JSON.

More prefixes from AS22284

Routes seen by RIPE RIS in the 24 hours up to 15 Sep 2026, 21:24 UTC, fetched just now.
