AS4713 NTT DOCOMO BUSINESS,Inc.

AS4713 NTT DOCOMO BUSINESS,Inc. announces 181 IPv4 prefixes and 6 IPv6 prefixes. The map below is for 153.128.0.0/10, the largest of them that RIPE RIS can see: 328 collector peers reach it over 253 AS paths, most often through AS2914 NTT America, Inc. (98%).

Routes checked 14:44:33 UTC

No change in the origin, the upstreams or the number of peers since 14:44 UTC, when this site first looked at 153.128.0.0/10.

AS-path graph toward 153.128.0.0/10
BGP map of 153.128.0.0/1010 networks on the paths RIPE RIS collector peers use to reach 153.128.0.0/10. Best path, chosen by the most peers: AS24482 → AS2914 → AS4713.AS8218 → AS6461 · 7 routesAS6461 → AS2914 · 12 routesAS9002 → AS2914 · 4 routesAS12779 → AS2914 · 4 routesAS13030 → AS1299 · 4 routesAS1299 → AS2914 · 8 routesAS199524 → AS1299 · 4 routesAS24482 → AS2914 · 11 routes · best pathAS2914 → AS4713 · 55 routes · best pathAS4713 → 153.128.0.0/10 · 55 routes · best path7AS8218 → AS6461 · 7 routes12AS6461 → AS2914 · 12 routes4AS9002 → AS2914 · 4 routes4AS12779 → AS2914 · 4 routes4AS13030 → AS1299 · 4 routes8AS1299 → AS2914 · 8 routes4AS199524 → AS1299 · 4 routes11AS24482 → AS2914 · 11 routes · best path55AS2914 → AS4713 · 55 routes · best path55AS4713 → 153.128.0.0/10 · 55 routes · best pathT1AS2914NTT America, Inc.AS2914 NTT America, Inc. · Tier 1 · 55 routes · on the best pathAS4713NTT DOCOMOBUSINESS,Inc.AS4713 NTT DOCOMO BUSINESS,Inc. · origin · 55 routes · on the best pathT1AS6461Zayo BandwidthAS6461 Zayo Bandwidth · Tier 1 · 12 routesAS24482SG.GSAS24482 SG.GS · edge network · 11 routes · on the best pathT1AS1299TWELVE99 ArelionSweden ABAS1299 TWELVE99 Arelion Sweden AB · Tier 1 · 8 routesAS8218NEO-ASN ZayoInfrastructure France SAAS8218 NEO-ASN Zayo Infrastructure France SA · edge network · 7 routesT2AS9002RETN-AS RETN LimitedAS9002 RETN-AS RETN Limited · Tier 2 · 4 routesAS12779ITGATE IT.Gate S.p.A.AS12779 ITGATE IT.Gate S.p.A. · edge network · 4 routesT2AS13030INIT7 Init7(Switzerland) Ltd.AS13030 INIT7 Init7 (Switzerland) Ltd. · Tier 2 · 4 routesAS199524GCORE G-Core Labs S.A.AS199524 GCORE G-Core Labs S.A. · edge network · 4 routes153.128.0.0/10153.128.0.0/10

origin Tier 1Tier 2edge network prefix best path: chosen by 11 of 328 peers (3%) number on a line = peers using that link RIS data up to 14:44 UTC what the colours mean 12 of 253 paths drawn 4 quieter networks left out

Download PNG View JSON Raw upstream Full map of 153.128.0.0/10 →

Upstreams of 153.128.0.0/10

Networks directly in front of the origin, counted over the paths the collector peers use.

NetworkPeersShare
AS2914 NTT America, Inc.32098%
AS2497 Internet Initiative Japan Inc.2<1%
AS2516 KDDI CORPORATION2<1%
AS4777 Asia Pacific Network Information Centre1<1%
AS2500 WIDE Project1<1%
AS25152 K-ROOT-SERVER Reseaux IP Europeens Network Coordination Centre (RIPE NCC)1<1%
AS2518 BIGLOBE Inc.1<1%

IPv4 prefixes (181)

IPv6 prefixes (6)

Prefixes announced in the last two weeks, as seen by RIPE RIS.
